Tie Rod End - Right Side SP-D600 817019

This straight-style tie rod end is designed for right-hand (RH) installation in steering linkage assemblies. It includes a boot-type seal and integrated purge valve for serviceability. Constructed with precision-machined tapers and threaded connections, it ensures proper steering geometry and load handling.

• Mounting Position: Right-hand (RH)
• Rod Thread Size: 1.125‑12 inches
• Stud Thread Size: 0.875‑14 inch
• Rod End Thread Size: 1.250‑12 inches
• Taper Length: 1.06 inches
• Taper Minor Diameter: 0.97 inch
• Taper Major Diameter: 1.07 inches
• Ball Center to Castle Nut Thread Length: 2.22 inches
• Rod End to Socket Center Length: 6.19 inches
• Rod End Thread Length: 4.09 inches
• Type: Straight
• Seal Type: Boot
• Purge Valve: Included
