Tie Rod End - Left Side 817018

This straight-style tie rod end is designed for left-hand (LH) installation in steering linkage systems. It features a boot seal and integrated purge valve for grease servicing. Machined to fit standard taper dimensions, it supports precise steering alignment and load handling.

• Mounting Position: Left-hand (LH)
• Rod End Thread Size: 1.125‑12 inches
• Taper Length: 1.06 inches
• Taper Minor Diameter: 0.97 inch
• Taper Major Diameter: 1.07 inches
• Ball Center to Castle Nut Thread Length: 2.22 inches
• Rod End to Socket Center Length: 6.19 inches
• Rod End Thread Length: 4.09 inches
• Type: Straight
• Seal Type: Boot
• Purge Valve: Included
