Fuel Filter FF5207

Part Details:

• Overall Height:
  • 8.09-inches / 205.49 mm
• Largest Outside Diameter:
  • 3.666-inches / 93.12 mm
• Seam Outside Diameter:
  • 3.69-inches / 93.73 mm
• Gasket Outside Diameter:
  • 3.49-inches / 88.65 mm
• Gaskget Inside Diameter:
  • 3.115-inches / 79.12 mm
• Thread Size:
  • 1-12 UNS-2B
• Standpipe:
  • No
• EFFICIENCY, TWA BY SAE J 1858:
  • 98.7%
• MICRON RATING BY SAE J 1858:
  • 50 micron
• Primary Applications:
  • AC - TP915D
  • DETROIT DIESEL - 25014274
  • GMC - 25014274
• Uses Service Part:
  • 3833199S - Fuel Filter Head for Spin-On Conversion of Primary Fuel FF5207 for Detroit Diesel applications.
• Is A Longer Version of:
  • FF235
• For Upgrade, Use:
  • FS19513
