Yoke - End, Half Round, Assembly 170-4-321-1X

Spicer
Part# 170-4-321-1X
note
Yoke - End, Half Round, Assembly 170-4-321-1X - Spicer

Half Round End Yoke Assembly

Package discount applied. Your savings:
info
Extended Lead Time
Have a Question?
Live Chat chat or Contact us

Description

Half Round End Yoke Assembly

Part Details:

  • Spline Quantity: 41
  • Series: SPL170
  • Joint Angle: 45 degrees
  • Slinger/Plug included: Yes
  • Yoke Style: HR
  • Material: Steel
  • Type: Splined Hole
  • involute Spline: Yes
  • Center To End Length: 7.19 inches
  • Major Diameter: 2.14 inches
  • Spline Diameter: 2.14 inches
  • Spline Length: 3 inches
  • Yoke Bearing Diameter: 2.17 inches
  • Outside Hub Diameter: 2.93 inches
  • Hole Length: 3 inches
  • Counter Bore Depth: 0.38 inch
  • Universal Joint Retaining Width: 6.45 inches
  • Outer Yoke Length: 6.46 inches
  • Yoke To Yoke Total Length: 6.45 inches
  • Hub Diameter: 2.94 inches
  • Bearing Center to Hub End Length: 7.19 inches

Check Out All Of Our Yoke Components!



Shipping Info

Next Day Air services are available for In Stock items. Our shipping cutoff time is Monday - Friday 4:30pm Eastern Standard Time (EST).



For more shipping information, please see our Shipping & Delivery page.

More Information

Current Part# 170-4-321-1X
Part# variations SP 170-4-321-1X,
SP170-4-321-1X
Manufacturer Spicer
Fits Freightliner
