Valve 289129N

Part Details:

• Weight: 2.43 kg
• Spring Material: Rubber
• Pedal Material: Steel
• Exhaust Port Type: Dust Shield
• Plunger Material: Steel
• Style: E-6
• Delivery Port Quantity: 4
• Pedal Angle: 27 degrees
• Water Resistance: No
• Rubber Boot Included: Yes
• Regulatory Compliance: FMVSS 121
• Retarder Included: No
• Pedal Style: Floor-Treadle
• Pedal Pad Included: Yes
• Pedal Included: Yes
• Mounting Plate Included: Yes
• Port Configuration: Axial/Perpendicular
• Differential Pressure: 3 psi
• Pedal Length: 10.94 inches
• Total Pedal Travel: 20 degrees
• Valve Body Mounting Thread Size: 5/16-18 UNC-3B in
• Vehicle Mounting Dimension: 0.34 inch
• Delivery 21 Port 1 Thread Size: 3/8-18 NPT inch
• Delivery 21 Port 2 Thread Size: 3/8-18 NPT inch
• Delivery 22 Port 2 Thread Size: 3/8-18 NPT inch
• Delivery 22 Port 1 Thread Size: 3/8-18 NPT inch
• Supply 11 Port 2 Thread Size: 3/8-18 NPT inch
• Supply 12 Port 1 Thread Size: 3/8-18 NPT inch
• Supply 12 Port 2 Thread Size: 3/8-18 NPT inch
• Supply 11 Port 1 Thread Size: 3/8-18 NPT inch
• Minimum Operating Temperature: -40 Deg.F
• Maximum Operating Temperature: 200 Deg.F
