Valve 118316

This valve is a two-position, four-port control valve designed for managing double-acting pneumatic cylinders—commonly used for power take-off (PTO) and equipment shifting in heavy-duty trucks.

• Function: two-position, four-port actuator control
• Operation: spring-loaded lockout on the lever to prevent unintentional shifting
• Valve type: non-compensating (direct on/off flow control)
• Flow capacity: approximately 15 SCFM at 100 psi
• Ports: four total, with standard 1/8inch NPT fitting size (base)
• Construction: rugged housing suitable for truck air systems
• Intended use: control of pneumatic cylinders in chassis-mounted equipment
• Exact fit: OEM design matching heavy-duty transmission and PTO systems
• Confirm compatibility with specific vehicle model before installation
