30 Series Low Profile Red Marker/Clearance Light

In stock
Part# 30285R OLD# -

30 Series, LED, Red Round, 6 Diode, Low Profile, M/C Light, PC, 12V


30 Series, Low Profile, LED, Red Round, 6 Diode, Marker Clearance Light, PC, PL-10, 12V

  • Highest quality LED Lighting products on the market from a brand you can trust.
  • Most advanced and cost effective 2" clearance and marker lamp.
  • LEDs have no filament, therefore are not susceptible to shock and vibration.
  • Less current draw, resulting in increased battery and alternator life while allowing more power for other vehicle requirements.
  • SAE PC-rated for combination clearance/marker applications.
More Information
Current Part# 30285R
Stock In stock
Voltage 12
Manufacture Warranty 3-Year
Manufacturer Truck Lite
Lighting Technology LED
Number of diodes / bulbs 6
Series 30 Series
Std Pack QTY 1
Lamp connection PL-10
Kit No
Lens Shape Round
Lens color Red
Housing Material Polycarbonate
Lens Material Polycarbonate
Mount Type Grommet Mount
Common Size (in) 2
Lens Width (in) 2.25
Lens Height (in) 2.25
Total Height (in) 2.25
Total Width (in) 2.25
Total Depth (in) 1.06
Weight 0.2000
