Price $954.20
Pump - V10F1P7P38C4H20L
Description
Pump - V10F1P7P38C4H20L
- Big Rig World carries Genuine OEM and Aftermarket brand parts to repair your vehicle at the lowest prices.
Vickers
574739-7
Pumps - V10F 1P7P 38C4H 20 LH
Model Code: V10F-1P7P-38C4H-20-L
| Feature | Code | Description |
|---|---|---|
| SEAL | _ | STANDARD SEALS |
| SERIES | V10 | V10 |
| COVER TYPE | F | FLOW CONTROL COVER & RELIEF |
| MOUNTING | -1 | 2-BOLT FLANGE |
| INLET PORT CONNECTIONS | P | 1" NPT THREAD |
| SAE RATED CAPACITY | 7 | 26 L/MIN (7 US GPM) |
| OUTLET PORT CONNECTIONS | P | 1/2" NPT THREAD (V10 ONLY) |
| SHAFT SEAL TYPE | _ | OMIT FOR SINGLE LIP SEAL AND SEALED BEARINGS |
| SHAFTS | -38 | SPLINED - 11 TOOTH - 3/4" OUTER DIAMETER |
| POSITION OF OUTLET | C | IN LINE WITH INLET |
| ORIFICE NO. 1 FLOW RATE | 4 | 15 L/MIN (4 US GPM) |
| PRESSURE SETTING | H | 138 BAR (2000 PSI) |
| DESIGN | -20 | (V10) |
| SHAFT ROTATION | -L | LEFT HAND (COUNTERCLOCKWISE) |
| SPECIAL | _ | NONE |
Shipping Info
Please note, next day services are only available for In-Stock items. If an order ships on a pallet with an LTL Freight Service, the shipping quotes are based on commercial addresses only. If you require delivery to a residential address or farm, please contact us. For more shipping information, please see our Shipping & Delivery page.
Product details
| Current Part# | 574739-7 |
|---|---|
| Manufacturer | Eaton |
| Stock | Special Order |
| Hot Deals | No |
| Warranty | Standard Manufactures |
