Price $954.20
Pump - F3V20F1R11P38C6H22L
Description
Pump - F3V20F1R11P38C6H22L
- Big Rig World carries Genuine OEM and Aftermarket brand parts to repair your vehicle at the lowest prices.
GENERAL SPECIFICATIONS
PRODUCT NAME: Eaton Vickers V10 and V20 Series Vane Pumps
CATALOG NUMBER: 02-137052-7
PRODUCT LENGTH/DEPTH: 8.32 IN
PRODUCT HEIGHT: 4.79 IN
PRODUCT WIDTH: 5.12 IN
PRODUCT WEIGHT: 18 LB
WARRANTY: Hydraulics Warranty
PRODUCT SPECIFICATIONS
VANE FUNCTION TYPE Pump
FRONT OUTLET PORT POSITION (COVER END VIEW) INLINE WITH INLET PORT
SPECIAL FEATURES None
FRAME SIZE V20
CONFIGURATION Single
MAXIMUM WORKING PRESSURE 172 b
PRODUCT MATERIAL Cast Iron
RING SIZE 11
FLOW RATE 86.7 LQ
IDENTIFICATION None
DESIGN CODE 22
DISPLACEMENT 36.4 CCR
SEAL MATERIAL Viton
SHAFTS Splined - 11 Tooth - 3/4"" Outer Diameter
SERIES V20
SHAFT ROTATION Left
MINIMUM SPEED 2500 RPM
INLET PORT CONNECTIONS Standard 1.000 BSPF
APPLICATION Oil and Gas, Metal Cutting, Dump Truck, Wheel Loader, Plastic Injection Molding
FRONT FLANGE MOUNTING STYLE SAE J744 101-2 (SAE B) 2 Bolt
Shipping Info
Please note, next day services are only available for In-Stock items. If an order ships on a pallet with an LTL Freight Service, the shipping quotes are based on commercial addresses only. If you require delivery to a residential address or farm, please contact us. For more shipping information, please see our Shipping & Delivery page.
Product details
| Current Part# | 02-137052-7 |
|---|---|
| Manufacturer | Eaton |
| Stock | Special Order |
| Hot Deals | No |
| Warranty | Standard Manufactures |
