Pump 02-137032-7

General Specifications:

• Product Name: Eaton Vickers V10 and V20 Series Vane Pumps
• Catalog Number: 02-137046-7
• Product Length/Depth: 8.12 inches
• Product Height: 4.79 inches
• Product Width: 5.12 inches
• Product Weight: 18 lbs
• Warranty: Hydraulics Warranty

Product Specifications:

• Vane Function Type: Pump
• Front Outlet Port Position (Cover End View): Inline with Inlet Port
• Special Features: None
• Frame Size: V20
• Configuration: Single
• Maximum Working Pressure: 172 b
• Product Material: Cast Iron
• Ring Size: 9
• Flow Rate: 75 LQ
• Identification: None
• Design Code: 22
• Displacement: 29.7 CCR
• Seal Material: Viton
• Shafts: Splined - 11 Tooth - 0.75 inch Outer Diameter
• Series: V20
• Shaft Rotation: Left
• Minimum Speed: 1800 RPM
• Application: Oil and Gas, Metal Cutting, Dump Truck, Wheel Loader, Plastic Injection Molding
