Power Steering Pump 576253-3

positive OEM
Eaton
Part# 576253-3
note
Power Steering Pump 576253-3 - Eaton

Power Steering Pump

Package discount applied. Your savings:
info
Extended Lead Time
non-returnable Non-returnable info
Have a Question?
Live Chat chat or Contact us

Description

Power Steering Pump

- Big Rig World carries Genuine OEM and Aftermarket brand parts to repair your vehicle at the lowest prices.

Vickers

576253-3

Pumps - 2520VQ17C11 11CC20
Model Code: 2520VQ17C11-11CC-20

Product Specifications

FeatureCodeDescription
SEALTYPE _ STANDARD
FRAME SIZE 2520 2520
PUMP SERIES VQ INTRAVANE PUMPS
THRUDRIVE _ NO THRU-DRIVE
PILOT DESIGNATION _ OMIT FOR STANDARD PILOT
INTEGRAL VALVE OPTIONS _ OMIT IF INTEGRAL VALVE NOT REQUIRED
GEOMETRIC DISPLACEMENT - SHAFT END 17 17 (USGM) 64.37 (L/MIN) - SAE RATING (USGPM) @ 1200 RPM AND 7 BAR (100 PSI)
REAR MOUNTING FLANGE & ORIENTATION C (C)SAE B 2 BOLT FLG INLINE WITH PUMP MTG FLG
GEOMETRIC DISPLACEMENT - COVER END 11 11 (USGM) 41.65 (L/MIN) - SAE RATING (USGPM) @ 1200 RPM AND 7 BAR (100 PSI)
MOUNTING AND SHAFT SEAL ASSEMBLY _ FLANGE MOUNT AND SINGLE SHAFT SEAL
SHAFT -11 SPLINED MDF
PORT ORIENTATION CC WITH NO.1 OUTLET INLINE WITH INLET AND NO.2 OUTLET 45+ CW FROM INLET
CONTROLLED FLOW RATE AND RELIEF VALVE SETTING _ NOT APPLICABLE
DESIGN NUMBER -20 20
SHAFT ROTATION _ RIGHT HAND (CW) - AS VIEWED FROM SHAFT END
SUFFIX _ NONE

Shipping Info

Next Day Air services are available for In Stock items. Our shipping cutoff time is Monday - Friday 4:30pm Eastern Standard Time (EST).



For more shipping information, please see our Shipping & Delivery page.

More Information

Current Part# 576253-3
Type OEM
Part# variations 576253-3 DAN,
576253-3 ETN,
576253-3DAN,
576253-3ETN,
ETN576253-3
Manufacturer Eaton
Warranty Standard Manufacturer Warranty
