PTO - 4100 SAE 8 Hole, Heavy Duty 4100XJN011SE

- Big Rig World carries Genuine OEM and Aftermarket parts to repair your vehicle at the lowest prices.

The 4100 series is a heavy-duty PTO with a 475 ft./lb. torque rating, in a lightweight and compact package. It’s able to fit applications that require high torque demands and is smaller and lighter than competitive products for nearly all applications.

Industry leading weight-to-torque ratio provides outstanding performance for the price.
Low profile, compact PTO is lighter and easy to install.
Large, oversize bearings provide long life on higher torque applications such as blowers.
Robust, integrated air shifter in the housing features a smooth engagement design to reduce clash shifting.
Industry leading gasket material and Viton O-ring material & shaft seals.
Competitive with:
Muncie CS8, Chelsea 680
Torque ratings: up to 470 lb. ft. Rates higher than the CS8 and 680

Typical Applications:

Blowers
Log Loaders
And more….

Engine to PTO ratio
INTERNAL RATIO
INTERMITTENT SERVICE
CONTINUOUS SERVICE
Torque
(Lb. FT)
Power (HP)
Torque
(Lb. FT)
Power (HP)
At 500  r.p.m.
At 1000 r.p.m.
At 500  r.p.m.
At 1000 r.p.m
57%(B)
450
44
87
317
31
62
70%(C)
470
45
90
340
33
65
86%(E)
470
45
90
340
33
65
105%(J)
400
39
77
300
29
58
