APTIV Heavy Duty AM/FM/WB with Front Panel USB Port PP807155

- Big Rig World carries Genuine OEM and Aftermarket parts to repair your vehicle at the lowest prices.

COMMON FEATURES FOR ALL HEAVY-DUTY APTIV RADIOS:

*HEAVY-DUTY DESIGN – made for a commercial vehicle driver by having larger buttons and a heavy-duty construction for tougher environments.
*SAE J1455 COMPLIANT – meets all the test standards for reliability of an electronic component in a commercial vehicle.
*WEATHER BAND (WB) – offers National Weather Radio Broadcasts from over 1,025 locations throughout the United States on seven VHF/FM frequencies free-of-charge to provide continuous    weather information 24 hours a day. Range: 162.400 MHz – 162.550 MHz
*ISO CONNECTOR – allows the radio to be connected directly to the vehicle’s harness; no additional harness is required – no cutting, no separate accessories to purchase for all commercial          vehicles manufactured with the ISO connect harness.
*FRONT AUX INPUT (MUSIC PORT) – easy access to plug in a smart device and enjoy your digital music library through the vehicle’s speakers.
*REAR AUX INPUT – provides an auxiliary terminal for permanent hard wire to the rear side of the radio.
*SAE J1939 COMPLIANT – allows the different vehicle components that run on the communication bus system to talk to each other, compatible with most digital steering wheel/rear-sleeper controls.
*QUARTZ ALARM CLOCK – convenient, built-in quartz alarm clock with one hour timer.
*OUTPUT POWER – 18 Watts x 4 Channels, 18 Watts x 2 Channels (24 Volt Radios)
*SOUND QUALITY (EQ) FUNCTION – select the sound type (Pop, Rock, Country, News, Jazz, Classical or Manual) to improve the dynamic range
*SEPARATE BASS, MID, TREBLE, BALANCE AND FADER CONTROL
*6 AM / 12 FM RADIO PRESET BUTTONS
*AUTO STORE MEMORY
*AUTO BAUD RATE – capable of auto detecting the correct CAN bus baud rate to use at power up; the possible baud rate is 250K or 500K.
*MECHLESS – no Compact Disc (CD) Player
*SHALLOW CLASSIS – 86.5 mm in depth
*VF DOT MATRIX DISPLAY – three line display that maximizes the viewing area on the front of the radios. This allows for more information on the screen and minimizes the need to scroll.
*WHITE FAKRA AM/FM ANTENNA CONNECTOR – robust locking mechanism, small form factor with high speed capability which allows for better cable management.
*MOTOROLA TO FAKRA ADAPTER CABLE – AM/FM Radio Antenna Adapter Fakra Jack code B to Motorola DIN socket connector six-inch cable. Adapter cable included with each APTIV radio model until OEM truck manufacturers change wiring from Motorola to FAKRA.

PRODUCT FEATURES:

*APTIV Radio (PP107201), Bluetooth® Microphone (PP604240) and interoperable Satellite Radio Antenna (SRTMM-02)
*Integrated SiriusXM Satellite Radio Tuner – offers 100+ channels of digital quality audio programming heard uninterrupted across the continuous United States and Canada; a subscription is required to receive satellite broadcasts*
*SiriusXM ‘Instant Replay’ feature enabled – allows user to pause, rewind and replay audio content from the currently active channel
*Built-in Bluetooth® profile is selectable between Audio Streaming and/or Hands-Free phone operation (utilizing the vehicle’s audio system and a remote mic** – up to 10 devices can be easily stored in the radio memory for fast pairing)
*Front Panel USB Port – gives a direct connect location for memory devices with USB interface, to play stored music and/or charge the device and have iPod control through the radio
*iPad charging capability up to 21.A
*Back-lit Display Lighting – GREEN or AMBER
*Handheld Remote Control sold separately – Part No. PP603988

**Satellite Radio Antenna INCLUDED – Part No. SRTMM-02
**Bluetooth® Mic INCLUDED – Part No. PP604240

MICROPHONE FEATURES:

*Allows hands-free phone calls with the Bluetooth® feature of this radio
*Designed to be secured to a surface with double sided adhesive tape
*3/4″ wide x 1-5/8″ tall
*No need to drill a hole in the instrument panel
*7.5′ cable includes a connector that plugs directly into the back of the radio

SATELLITE RADIO ANTENNA FEATURES:

*Interoperable (certified for use with SiriusXM receivers)
*Mirror-mount design
*14-foot RG-174 cable
*Custom SMB connector to fit Delphi radios
*Durable, light weight and sleek
