Midship Tube Shaft 250-53-11

Spicer
Part# 250-53-11
note
Midship Tube Shaft 250-53-11 - Spicer

Midship Tube Shaft

Package discount applied. Your savings:
info
Extended Lead Time
Have a Question?
Live Chat chat or Contact us

Description

Midship Tube Shaft

Part Details:

  • Style: 2
  • Spline Quantity: 46
  • Series: SPL250
  • Material: Steel
  • Spline Type: Involute
  • involute Spline: Yes
  • Wall Thickness: 0.23 inches
  • Thread Size: M30 X 2-6G mm
  • Shoulder Diameter: 2.89 inches
  • Spline Diameter: 2.35 inches
  • Spline Length: 2.62 inches
  • Tube Diameter: 5.19 inches
  • Bearing Diameter: 2.36 inches
  • Butt Diameter: 4.75 inches
  • Shoulder Length: 0.81 inch
  • End Of Spline To Bearing Shoulder: 3.98 inches
  • Spline End to Weld Length: 5.29 inches
  • Compatible Tube Wall Thickness: 0.15 inch
  • Compatible Tube Diameter: 5.19 inches
  • Spline Outer Diameter: 2.35 inches

Check Out All Of Our Drive Shaft Components!



Shipping Info

Next Day Air services are available for In Stock items. Our shipping cutoff time is Monday - Friday 4:30pm Eastern Standard Time (EST).



For more shipping information, please see our Shipping & Delivery page.

More Information

Current Part# 250-53-11
Part# variations SP 250-53-11,
SP250-53-11
Manufacturer Spicer
Fits Freightliner
Material Steel
