We will order this part from the manufacturer specifically for you. Estimate lead times are 3 to 6 weeks, but can vary. To expedite the part with an expedite fee (if available), or with questions on shipping expectations please contact us.
- Big Rig World carries Genuine OEM and Aftermarket brand parts to repair your vehicle at the lowest prices.
Prestolite / Leece-Neville has a proud tradition of engineering the highest quality starter motors available. A leading supplier for the US Military for years, the same demanding design disciplines are brought into every product we bring to market.
We are now leveraging our global manufacturing capabilities to offer a quality starter motor for almost any application.
Product Specifications
Spec
Value
Item number
M110R2610SE
Sales number
M110610
Series number
M110
Special Note
Conditions Of Usage
Warning: Prestolite Products are not approved for Aviation applications!
Notes
SPECIAL APPLICATION NOTE: IF THERE IS A SHIM IN PLACE BETWEEN THE STARTER AND THE BELL HOUSING. IT MUST REMAIN IN PLACE WHEN INSTALLING THE REPLACEMENT STARTER.
System voltage
12
kW
7.0
Dimensions in
MILLIMETERS
Rotation
CLOCKWISE
Housing coating
E-COAT
UL Approved
No
Pinion teeth
12
Pinion pitch
8/10
Pinion OD
46.6
Pinion at rest
47.5
Span over 2 teeth
15.59-15.68
Flange type
SAE J542 Type 3
Flange image
Switch position
292.5°
Helper Relay
-90
Ignition terminal
M5
Battery terminal
M12X1.75
Ground terminal
M12X1.75
Wetclutch
Yes
Overcrank Protection
Yes
