High Temp Wire-Braided Air Discharge Line #10 A12-23236-014

This air discharge line is designed for high-temperature air systems. It features an EPDM synthetic rubber hose with a steel wire braid and straight female swivel fittings on both ends. The hose is constructed for durability and consistent performance under high thermal and pressure conditions.

• Overall Length: 14 inches
• Hose Length: 11.56 inches
• Hose Inner Diameter: 0.50 inches
• Hose Outer Diameter: 0.83 inches
• Hose Wall Thickness: 0.17 inches
• Standard Hose Size: #10
• End 1 Fitting Type: Female swivel straight fitting
• End 2 Fitting Type: Female swivel straight fitting
• End 1 Thread Size: 7/8-14 inches
• End 2 Thread Size: 7/8-14 inches
• Hose Material: EPDM (synthetic rubber)
• Nut Material: Steel
• Nipple Material: Brass
• Color: Black
• Working Temperature Range: -40 to +311 °F
• Working Pressure: 250 psi
• Burst Pressure: 1000 psi
