Cooler Discharge Pipe P4 Heavy Duty Engine Platform A12-29038-000

This air discharge pipe is used on the P4 heavy duty engine platform to route compressed air between components in the cooling system. Constructed from steel tubing with brass male flare fittings, it is zinc-plated for corrosion resistance and designed to handle high-pressure air flow. Both ends feature 7/8-14 inch threaded connectors with 45-degree flares.

• Overall Length: 57.73 inches
• Center to Center Length: 27.65 inches
• Tube Outer Diameter: 0.75 inch
• Tube Inner Diameter: 0.61 inch
• Tube Wall Thickness: 0.07 inch
• End 1 Fitting Type: Male connector
• End 2 Fitting Type: Male connector
• End 1 Thread Size: 7/8-14 inch
• End 2 Thread Size: 7/8-14 inch
• End 1 Flare Fit Angle: 45 degrees
• End 2 Flare Fit Angle: 45 degrees
• Tube Material: Steel
• Nut Material: Brass
• Finish: Zinc plated
