High Temp #10 Wire Braid Hose Assembly 15-inches A12-23236-015

This wire-braided EPDM hose assembly is designed for high-temperature compressed air applications. It features female swivel straight fittings on both ends and provides reliable performance within specified temperature and pressure limits. The hose has a 15-inch overall length and fits #10 air line connections.

• Overall Length: 15 inches
• Hose Length: 12.56 inches
• Hose Inner Diameter: 0.50 inches
• Hose Outer Diameter: 0.83 inches
• Hose Wall Thickness: 0.17 inches
• Standard Hose Size: #10
• End 1 Fitting Type: Female swivel straight fitting
• End 2 Fitting Type: Female swivel straight fitting
• End 1 Thread Size: 7/8-14 inches
• End 2 Thread Size: 7/8-14 inches
• Hose Material: EPDM (synthetic rubber)
• Nut Material: Steel
• Nipple Material: Brass
• Color: Black
• Working Temperature Range: -40 to 311 degrees Fahrenheit
• Working Pressure: 250 psi
• Maximum Working Pressure: 250 psi
• Burst Pressure: 1000 psi
• Minimum Burst Pressure: 1000 psi
