Hub Assembly 26561-0T

HUB INFORMATION
Part Number: 26561--0T
Hub Number: 2656
Description: 10 Stud Hub w/11.25 (285.75MM) Dia. Bolt Circle. Uses Outboard Drum
Hub Material: Cast
Mounting Type: BSN or FN
Drum Type: Outboard
Disc Wheel: N/A
Wheel Stud: N/A
Stud Stand Out: N/A
ABS Ring: Direct Machined ABS
Drum Options: 61577B, 61988B, 61991B, 66661B, 66864B, 66884B, 66800B, 66814B, 66854B, 66871B, 77864B
Drum Type: Outboard
Number of Studs: 10
Bolt Circle: 11.25
Stud Description: M22 x 1.5 Serrated Stud or 3/4 In. - 16 Serrated Stud
Outer Bearing Cup: 572
Outer Bearing Cone: 580
Inner Bearing Cup: 592A
Inner Bearing Cone: 598A or 594A
Webb Axle Group: 23
Cup Code: 1
Notes: Stud Standout (Cast drums): Dimensions shown are for brake drums having (.50) back plate thickness. Deduct (.06) from these dimensions when using brake drums having (.56) back plate thickness. Add (.25) to these dimensions when using brake drums having (.25) backface
This hub designed for dual wheel mounting or single wheels with 1/2 In. maximum offset. Stud standout (cast drums)
Short Drive, Drive Stud P/N: 161832 (5/8 In.-18) x 8. 7.00 In. Bolt Circle
