Hub Assembly - 3T Is Stud Standard For Dual Steel Wheels 20231-3T
Hub Assembly - 3T IS Stud Standout For Dual Steel Wheels - Hub/Cup/Stud/ABS Sub-Assy - TN Trailer Application
Ships Oversize or LTL Freight.
Please call 1-855-274-8401 or Email before placing an order.
Hub/Cup/Stud/ABS Sub-Assembly - TN Trailer Application
Part Details:
- Meets Product Specific SAE Standards
- Stringent Testing for Maximum Performance and Consistency
- Made in the USA
- Hub Information:
- Description: 10 Stud Hub w/11.25 (285.75MM)Dia. Bolt Circle. Uses Outboard Drum (M22 x 1.5) Serrated Stud
- Hub Material: Cast
- Mounting Type: FN
- Drum Type: Outboard
- Disc Wheel: Steel (Dual)
- Wheel Stud: 101162
- Stud Stand Out: 3.25
- ABS Ring: Direct Machined ABS
- Drum Options: 61577F, 68985F, 66800F, 66864F, 66884F, 66814F, 66854F, 66871B
- Drum Type: Outboard
- Number of Studs: 10
- Bolt Circle: 11.25
- Stud Description: M22 x 1.5MM Serrated Stud
- Outer Bearing Cup: HM212011
- Outer Bearing Cone: HM212049
- Inner Bearing Cup: HM218210
- Inner Bearing Cone: HM218248
- Webb Axle Group: 2
- Cup Code: 1
- Hub Notes:
- Stud Standout (Cast drums): Dimensions shown are for brake drums having (.50) back plate thickness. Deduct (.06) from these dimensions when using brake drums having (.56) back plate thickness.
- This hub designed for dual wheel mounting or single wheels with 1/2 In. maximum offset.
Grease Hubcap Kit: 73655.
Drum Options:
| Drum/Rotor Number | Brake Size | Notes |
| 61577B | 7.00 | 0.50 Back Plate Thickness |
| 61577F | 7.00 | 0.50 Back Plate Thickness |
| 61988B | 8.62 | 0.50 Back Plate Thickness/For 19.5 In. Disc Wheel Approved for 19.5 disc wheels |
| 61988F | 8.62 | 0.50 Back Plate Thickness/For 19.5 In. Disc Wheel Approved for 19.5 disc wheels |
| 61991B | 8.62 | 0.50 Back Plate Thickness/For 19.5 In. Disc Wheel Approved for 19.5 disc wheels |
| 61991F | 8.62 | 0.50 Back Plate Thickness/For 19.5 In. Disc Wheel Approved for 19.5 disc wheels |
| 66800B | 8.00 | 0.56 Back Plate Thickness |
| 66800F | 8.00 | 0.56 Back Plate Thickness |
| 66814B | 8.62 | 7 inch centerline |
| 66814F | 8.62 | 7 inch centerline |
| 66854B | 8.62 | 0.56 Back Plate Thickness Oil Groove |
| 66854F | 8.62 | 0.56 Back Plate Thickness Oil Groove |
| 66864B | 7.00 | 0.50 Back Plate Thickness/Heavy Duty Drum |
| 77864BW | 7.00 | 0.50 Back Plate Thickness/Heavy Duty Drum |
| 66864F | 7.00 | 0.50 Back Plate Thickness/Heavy Duty Drum |
| 66871B | 10.00 | 0.50 Back Plate Thickness |
| 66871B | 10.00 | 0.50 Back Plate Thickness |
| 66884B | 7.00 | 0.50 Back Plate Thickness/Extra Heavy Duty Drum |
| 66884F | 7.00 | 0.50 Back Plate Thickness/Extra Heavy Duty Drum |
Flange Mount (FN) Details:
- Disc Wheel: Steel
- Tire Application: Dual
- Total Disc Wheel Thickness: .75 to 1.00
- Drum Type: Cast
- Right Hand Stud: 101162
- Stud Color: Black
- Stud Standout: 3.03
- Order Code: 3
- Disc Wheel: Aluminum
- Tire Application: Single
- Total Disc Wheel Thickness: .84 to 1.00
- Drum Type: Cast
- Right Hand Stud: 101162
- Stud Color: Black
- Stud Standout: 3.03
- Order Code: 3
- Disc Wheel: 1 1/8 In. Alum. (Super)
- Tire Application: Single
- Total Disc Wheel Thickness: 1.12
- Drum Type: Cast
- Right Hand Stud: 101162
- Stud Color: Black
- Stud Standout: 3.03
- Order Code: 3
Check Out All Of Our Hubs!
This Item Ships Oversize or LTL Freight
Please Contact Big Rig World for Shipping Costs before ordering. 1-855-274-8401 [email protected]
(Residential may not be available or have additional fees. Commercial Address Preferred)
Please note, next day services are only available for In-Stock items. If an order ships on a pallet with an LTL Freight Service, the shipping quotes are based on commercial addresses only. If you require delivery to a residential address or farm, please contact us. For more shipping information, please see our Shipping & Delivery page.
| Current Part# | 20231-3T |
|---|---|
| Manufacturer | Webb Wheel |
| Stock | Special Order |
| Hot Deals | No |
| Warranty | Standard Manufactures |
