Hose Assembly - Pressure Line , Medium Pressure A23-12005-054

- Big Rig World carries Genuine OEM and Aftermarket parts to repair your vehicle at the lowest prices.

Dimension

Length:                                         51.24 in
Outer Diameter:                           0.79 in
Inner Diameter:                            0.41 in
End 1 Thread Size:                    3/4-16 in
End 1 Flare Fit Angle:                   37 deg
End 2 Thread Size:                    3/4-16 in
End 2 Flare Fit Angle:                   37 deg
Standard Hose Size:                            #8

Temperature

Working Temperature Range:    -55 to +302 Deg.F

Construction

Material:                                    Elastomer
End 1 Fitting Type:                   Female Swivel
End 2 Fitting Type:                   Female Swivel
Hose Material:                          Synthetic Reinforced Rubber with SteelWire
Fitting Material:                        Steel

Performance

Working Pressure:                   2175 psi
Burst Pressure:                        8000 psi
