Fuel Filter FF5488

Part Details:

• Overall Height:
  • 6.92-inches / 175.77 mm
• Largest Outside Diameter:
  • 3.68-inches / 93.47 mm
• Seam Outside Diameter:
  • 3.67-inches / 93.22 mm
• Gasket Outside Diameter:
  • 2.83-inches / 71.88 mm
• Gasket Inside Diameter:
  • 2.46-inches / 62.48 mm
• Thread Size: 7/8-14 UNF-2B
• Standpipe: No
• EFFICIENCY, TWA BY SAE J 1985: 98.7 % (98.7 %)
• MICRON RATING BY SAE J 1985: 5 micron (5 micron)
• Primary Applications: CUMMINS - 3959612
• Additional Information: 335255 - Gasket
