Fuel Filter FF2203

Part Details:

• Dimensions:
  • Overall Height:
    • 5.78-inches / 146.81 mm
    • Largest Outside Diameter
    • 3.67-inches / 93.22 mm
  • Seam Outside Diameter
    • 3.67-inches / 93.98 mm
  • Gasket Outside Diameter
    • 2.83-inches / 71.88 mm
  • Gasket Inside Diameter:
    • 2.46-inches / 62.48 mm
  • Thread Size:
    • 1-14 UNS-2B
• Standpipe:
  • No
• EFFICIENCY, TWA BY SAE J 1985:
  • 96 % (96 %)
• MICRON RATING BY SAE J 1985:
  • 140 micron (140 micron)
• Primary Applications:
  • CUMMINS: 4010476
•  Is Substituted With:
  • FS1023 with Drain Valve
• Filter Used With:
  • 3833198S
• Additional Information:
  • 333849 Gasket
