Fuel Water Separator Filter FS1003

Part Details:

• Overall Height:
  • 9.79-inches / 248.67 mm
• Largest Outside Diameter
  • 3.69-inches / 93.73 mm
• Seam Outside Diameter
  • 3.68-inches / 93.47 mm
• Gasket Outside Diameter
  • 2.83-inches / 71.88 mm
• Gasket Inside Diameter
  • 2.46-inches / 62.48 mm
• Thread Size: 1-14 Uns-2b
• Standpipe: Yes
• Emulsified Water Separation: 95 % (95 %)
• Free Water Separation: 95 % (95 %)
• Efficiency, Twa By Sae J 1985: 98.7 % (98.7 %)
• Micron Rating By Sae J 1985: 10 Micron (10 Micron)
• Primary Applications: Cummins - 3406889
• Product Comments: Stratapore Media
• Is Metal Version Of: FS42263
• For Upgrade, Use: FS19596
• Filter Used With: FH126
• Additional Information: 3313108 - Gasket
