Filter Hydraulic HF6057

Part Details:

• Overall Height:
  • 5.84-inches / 148.34 mm
• Largest Outside Diameter:
  • 3.666-inches / 93.12 mm
• Seam Outside Diameter:
  • 3.692-inches / 93.78 mm
• Gasket Outside Diameter:
  • 2.834-inches / 71.98 mm
• Gasket Inside Diameter:
  • 2.462-inches / 62.53 mm
• Thread Size: 1-12 UNF-2B
• Standpipe: No
• ADBV: Null
• BPV Setting: 0 kPa (0 PSI)
• TWA MICRON @ BETA=2: 22 micron (22 micron)
• TWA MICRON @ BETA=20: 43 micron (43 micron)
• TWA MICRON @ BETA=200: 0 micron (0 micron)
• TWA MICRON @ BETA=75: 0 micron (0 micron)
• Primary Applications:
  • BUHLER - 2854
  • CROSS - 1A9023
  • GRESEN - 8057000
  • JOHN DEERE - AT38431
  • VOLVO - 100462
