Fifth Wheel - Elevating FW2900-5X

Part Details:

• MOV-ON™ HYDRAULIC ELEVATING FIFTH WHEELS
• When Hydraulics are Preferred and Extra Capacity is a Must.
• CAPACITY: 50,000 – 100,000 lbs. VERTICAL LIFT
• Available with Single Cylinder (50,000 lbs. lift capacity) and Twin Cylinder (100,000 lbs. lift capacity).
• A Variety of Lift Heights:
  • 14in
  • 15in
  • 18.5in
  • 19.5in

• Equipped with 8in I.D. Double Action Hydraulic Cylinders (Pump Up/Pump Down). Cold Weather Won’t Affect Lowering of Fifth Wheel.

• Optional Air Operated Lift Control Kit for Ease of Operation.

• Rigid, Rugged Construction. Weight is Carried Directly Over The Tractor Frame for Maximum Support and Efficient Load Distribution.

• Holland Twinlock™, Specially Designed for The Excessive Lock/ Unlock Demands of The Yard Tractor. Locks are forged Alloy Steel, Machined and Heat Treated for Maximum Wear and Toughness.

• Easily Accessible Grease Fittings for Ease of Maintenance.

• For Frequent Over-The-Road Usage On Public Streets Or Highways, The FW2800-X and Fw2900-X Models are Available with A Lock Down Option (Specify Option Code “87”). Note: Mounting Angles, Oil Tank and Filter Included with Basic Unit.
