End Yoke 5-4-7171-1

positive OEM
Spicer
Part# 5-4-7171-1
note
End Yoke 5-4-7171-1 - Spicer

End Yoke

Package discount applied. Your savings:
info
shipping-move Ships in 1-3 days
Have a Question?
Live Chat chat or Contact us

Description

End Yoke

Part Details:

  • Material: Steel
  • Type: Splined Hole
  • Spline Type: Involute
  • involute Spline: Yes
  • Model: 1610
  • Spline Quantity: 34
  • Series: 1610
  • Slinger/Plug included: No
  • Yoke Style: HR
  • Center To End Length: 4.13 inches
  • Major Diameter: 1.79 inches
  • Yoke Bearing Diameter: 1.88 inches
  • Hole Length: 2.25 inches
  • Bearing Diameter: 1.88 inches
  • Counter Bore Depth: 0.5 inch
  • U Joint Width: 5.31 inches
  • Outer Yoke Length: 5.31 inches
  • Hub Diameter: 2.19 inches
  • Bearing Center to Hub End Length: 4.13 inches
  • Counter Bore Diameter: 1.81 inches
  • Joint Angle 1: 22 degrees

Check Out All Of Our Driveshaft Components!



Shipping Info

Next Day Air services are available for In Stock items. Our shipping cutoff time is Monday - Friday 4:30pm Eastern Standard Time (EST).



For more shipping information, please see our Shipping & Delivery page.

More Information

Current Part# 5-4-7171-1
Type OEM
Part# variations SP 5-4-7171-1,
SP5-4-7171-1
Manufacturer Spicer
Warranty Standard Manufacturer Warranty
