Tie Rod End RH 1.62 Inch TRE12937

This right-hand tie rod end with a 1.62 inch taper is designed for use in heavy-duty truck steering systems. It features a straight design, includes a grease fitting, and is equipped with a polyurethane dust boot to ensure long service life and consistent steering performance.

• Form: Right-side straight tie rod end
• Function: Connects steering linkage for directional control
• Application: Heavy-duty truck steering systems
• Taper Dimensions:
  • Large diameter: 1.25 inches
  • Small diameter: 1.08 inches
  • Taper length: 1.36 inches
• Ball Stud Height: 2.6 inches
• Thread Size:
  • Connection 1: 1.25 inches
  • Connection 2: 0.875 inch
• Thread Direction: Left-hand (counter-clockwise)
• Dust Boot: Polyurethane included
• Grease Fitting: Yes (pre-greased)
• Overall Length: 7.5 inches
• Weight: 5.1 lb
