Draglink L24VU8338A11

This draglink is designed for use in steering systems, providing reliable connection and control between the pitman arm and steering arm. Manufactured to precise specifications, it ensures proper alignment and handling performance. The component features durable construction suitable for demanding commercial vehicle environments.

• Center-to-Center Length: 27.875 inches
• End-to-End Length: 14.50 inches
• Shaft Diameter: 1.44 inches
• Shaft Side Thread: 1-1/8-inch-12 (Right Hand)
• Taper Pin Minor Diameter: 1.08 inches
• Taper Pin Major Diameter: 1.25 inches
• Taper Pin Length: 1.36 inches
• Taper Pin Thread: 7/8-inch-14
• Gender: Male
