Diaphragm DP24L

positive OEM
Haldex
Part# DP24L
note
Diaphragm DP24L - Haldex
Flexible diaphragm converting air pressure to mechanical brake force.
Package discount applied. Your savings:
info
shipping-move Ships in 1-3 days
Have a Question?
Live Chat chat or Contact us

Description

The Haldex T-24 and T-24L Brake Chamber Diaphragm (HDX DP24L) is a flexible sealing component designed to convert air pressure into mechanical force within air brake chambers. It serves as a critical element in the brake actuation system, maintaining airtight integrity and enabling effective brake operation in commercial vehicle air brake assemblies.

Key Specifications

  • Application: Air brake chambers T-24, T-24L
  • Function: Converts air pressure to mechanical force
  • Compatibility: Heavy-duty trucks, commercial vehicles
  • Construction: Reinforced rubber diaphragm
  • Features: 7 in outer diameter, 2.25–2.50 in stroke length
  • Quality: OEM Haldex part

Shipping Info

Next Day Air services are available for In Stock items. Our shipping cutoff time is Monday - Friday 4:30pm Eastern Standard Time (EST).



For more shipping information, please see our Shipping & Delivery page.

More Information

Current Part# DP24L
Type OEM
Part# variations DP24L M1D,
DP24LM1D,
HDX DP24L,
HDXDP24L,
MID DP24L,
MIDDP24L
Manufacturer Haldex
Warranty Standard Manufacturer Warranty
