Carrier Bearing Assembly, Series 1710 CR00-67121

Part Dimensions:

• 9 1/4 inches (assembly)
• 2 1/4 inches (assembly)
• 6 5/16 inches (assembly)
• Center 2 25/32 inches (bearing)
• Inside Diameter: 50mm (bearing)
• Qty Per Vehicle: 1

Misc. Specs:

• Bolt Holes: 7 5/8 inches Center-to-Center
• Bolt Size: 1/2 inch
• Notes: Remove & do not reinstall the OE dust shield. Reusing the OE shield can cause noise & installation issues. Thoroughly clean all mating surfaces prior to reassembly.
  Hand tighten bolts to hold carrier bearing in place prior to torqueing to manufacturers specifications (varies by application).
