ABS Modulator Valve K128916OR

This ABS modulator valve is a unit outfitted for quick release brake systems in heavy-duty trucks. Featuring a robust die-cast metal and plastic housing, it incorporates dual solenoids (normally open and normally closed), an inlet/exhaust diaphragm, and quick-release bias valve. Designed for seamless plug-and-play replacement, it fits 1/2-inch PTC air ports and is controlled via a Metri-Pack 280 series 3-way sealed electrical connector.

• Valve Type: M‑40QR Quick‑Release ABS Modulator
• Ports:
• Supply: 1/2-inch 14 NPT PTC
• Delivery: 1/2-inch 14 NPT PTC
• Connector Type: Metri‑Pack 280 Series 3‑Way Sealed (Male)
• Voltage: 12 V
• Current Draw: ~4.6 A
• Operating Pressure: Up to 150 PSI
• Operating Temperature: –40 °F to +185 °F (–40 °C to +85 °C)
• Duty Cycle: 15 sec on / 5 min off; max solenoid "ON" time 150 sec
