1.63 x 6.07mm 90A NBR O-Ring 4J-7533

Part Details:

• SAE AS568 Dash Size: N/A
• Cross Section Diameter (in): 0.06
• Outside Diameter (in): 0.37
• Inside Diameter (in): 0.24
• Material: NBR (90),NBR - Nitrile,Nitrile (NBR)
• Material Description: Nitrile (NBR) rubber is capable of service temperatures of -40 to 100C and is resistant to fuel oils, gasoline, ultra low sulfur diesel fuel and lubricants. Nitrile rubber is not recommended for applications that require resistance to bio-diesel or coolant.
• Hardness (Shore A): 90
• Coating: PTFE coating protects the O-Ring from installation damage and provides ease of assembly.
• Color: Red
• Color Notes: Actual o-ring color may differ from image.
• Notes: Dimensions and material descriptions provided for reference only.
• Applications: Ambient temperature fuel handling; High and low pressure LPG service; Hydraulic fluids (to 10,335 kPa/1,500 psi); Power steering seals; Radiator thermostat seals
• Not Compatible With: Automotive and aircraft brake fluids; High levels of ozone; Ketones; Phosphate ester fluids; Strong acids; UV light
• Compatible With: Abrasion resistant; Alpha-Olefin base synthetic lubricants; Ethylene Glycol; Hydrocarbon fuels; Petroleum base lubricants; Silicone oils and greases; Water, water base engine coolants; ORFS, STORS seals
• Dash Size (in): 902
• Temperature (°F): -40 - 212
• Fitting Size (in): 5/16 – 24
• O-Ring Type: Straight Thread O-ring (STOR)
• Primary Sealing Material: Rubber
